NFC Anti-Metal FPC Material Tag 5.8X15mm

Supply NFC chip anti-metal FPC material label, using FPC anti-metal material, flexible and bendable, the label can be backed with adhesive, can be made into micro and small size, suitable for embedded applications such as smart toys, electronic products, etc., can be used as components to be assembled in products It can also be pasted on the surface of the product, suitable for anti-counterfeiting traceability supervision, touch sharing, mobile phone NFC reading applications, etc.



Main picture size: 5.8X15mm



Product parameters:

Label size: 5.8*15mm

Product thickness: 0.67mm±0.05mm (with glue and release paper thickness)

Substrate: PI

Main package material: Epistar+PI+etched copper wire+epoxy resin

Antenna Material: Copper Etched

Working frequency: HF 14.0MHZ

Memory capacity: 144 byte\1k byte\896 bit

Working Protocol: ISO/ICE 14443A

Tag chip: NTAG series, domestic Fudan, Feiju series, etc.

Read and write distance: 5-25mm

Read and write times: 100,000 cycles

Data retention: 10 years

Electrostatic protection: ±2KV



Environmental requirements:

Working temperature: -25℃-75℃

Storage temperature: 0℃-25℃



Package:

Anti-static bag packaging

1000-2000pcs per bag (depending on actual demand)

Packaging material: Bubble pad + anti-static bag + outer carton
